This tubing undergoes a rigorous quality inspection, including destructive and non-destructive examination, at the mill prior to shipment. This 9 point quality inspection examines:
- Strength - Tensile, Burst
- Hardness - Rockwell, Micro
- Soundness - Eddy Current, Ultrasonic, X-Ray
- Leak & Strength - Hydrostatic
- Leak - Air Under Water, Pressure Decay
- Bend Testing - Reverse Bending, Flattening, Reverse Flattening, Flange
- Dimensional - OD, Wall, Straightness
- Metallurgical - Grain Size, Sensitization, Corrosion, Phase Balance/Intermetallic, Metallographic
Standard |
ASTM, AISI, GB, JIS, customers' requests available |
Size |
Round Tube: OD: 16-119mm or customized |
Stainless Steel Polished Tube Thickness |
0.25mm-3.0mm |
Length |
6m or according to customers' request |
Sample |
Free sample is available, but freight should be paid by you |
Tolerance
|
Outer diameter: ±0.2mm |
Thickness: ±0.05mm |
|
Length: ±0.5mm |
|
Stainless Steel Polished Tube Ends |
In plain end or bevelled ends or as your requirements |
Welding Line Type |
ERW (Electrical Resistance Weld) |
Stainless Steel Polished Tube Finishing
|
A. Sanded |
B. Gloss #400,Mirror #600 - #1000 |
|
C. Brushed |
|
D. Wood Grain |
|
E. Embossed, Threaded |
|
Application |
Decorations, constructions, food industry, etc. |
Stainless Steel Polished Tube Certification |
ISO, SGS |
Round Pipe Size |
89, 17, 76.2, 31.8, 38.1, 50.8, 101, 36, 21, 23, 28, 60, 114, 63.5, 20, 22, 18, 35, 25, 19, 16, 48 millimeter |
Square Pipe Size |
17, 20, 36, 21, 25, 50, 23, 28, 38, 30, 19, 18, 22, 24,millimeter |
Rectangle Pipe Size |
10*40, 10*30, 20*10, 10*50, 24*12, 23*11, 28*25, 25*13, 29*14, 28*13, 30*20, 30*15, 34*22, 30*22, 50*25, 36*23, 75*45, 60*30, 95*45 millimeter |
Thickness |
exact 0.28, 1.15, 0.71, 1.41, 1.11, 0.32, 0.25, 0.51, 0.91, 0.37, 0.41, 0.61 millimeter |
Stainless Steel Polished Tube Length |
6m or according to customer’s request |
OD |
6.35 to 219 millimeter |
Tolerance |
Length :- ±0.5millimeter |
Outer diameter :- ±0.2millimeter |
|
Thickness :- ±0.02 millimeter |
|
Process method |
annealed with nitrogen protection, Code drawn, automatic shape ,ultrasonic, polished |
Stainless Steel Polished Tube Test |
Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
Equipment |
Bending machine, Press and electric bevelling machine, Pushing and Sand-blasting machineetc |
Origin |
Japanese / West Europe / USA / Indian / American /Korean / European |
Test Certificates |
Raw Materials Certificate, as per EN 10204 / 3.1B Manufacturer Test Certificate, Third Party Inspection Report, 100% Radiography Test Report |
| Dimensions | Wall | Weight per | Dimensions | Wall | Weight per | |
|---|---|---|---|---|---|---|
| (mm) | (mm) | metre (kg) | (mm) | (mm) | metre (kg) | |
| 12.7 x 12.7 | 1.20 | 0.44 | 40 x40 | 1.20 | 1.49 | |
| 12.7 x 12.7 | 1.50 | 0.55 | 40 x40 | 1.50 | 1.85 | |
| 15 x 15 | 1.20 | 0.53 | 40 x40 | 2.00 | 2.45 | |
| 15 x 15 | 1.50 | 0.65 | 40 x40 | 3.00 | 3.75 | |
| 20 x 20 | 1.20 | 0.71 | 50 x50 | 1.50 | 2.32 | |
| 20 x 20 | 1.50 | 0.88 | 50 x50 | 2.00 | 3.08 | |
| 20 x 20 | 2.00 | 1.19 | 50 x50 | 3.00 | 4.65 | |
| 25 x 25 | 1.20 | 0.92 | 60 x60 | 2.00 | 3.71 | |
| 25 x 25 | 1.50 | 1.14 | 60 x60 | 3.00 | 5.49 | |
| 25 x 25 | 2.00 | 1.49 | 70 x70 | 3.00 | 6.53 | |
| 25 x 25 | 3.00 | 2.20 | 80 x80 | 2.00 | 4.98 | |
| 30 x 30 | 1.20 | 1.10 | 80 x80 | 3.00 | 7.53 | |
| 30 x 30 | 1.50 | 1.37 | 100 x 100 | 2.00 | 6.40 | |
| 30 x 30 | 2.00 | 1.84 | 100 x 100 | 3.00 | 9.53 | |
| 30 x 30 | 3.00 | 2.72 | ||||
